| Model | ZYUPF-I-5L | ZYUPF-I-10L | ZYUPF-II-5L | ZYUPF-II-10L |
| Output(25°C)* | 5L/H | 10L/H | 5L/H | 10L/H |
| Flow rate | Up to 1.8 liters/minute(when water tank has water) | |||
| Feed water requirements | Tap water, temperature:5-45°C,pressure:1.0-4.0Kgf/cm2.TDS＜200ppm | |||
| RO water quality | ||||
| Condutivity(25°C) | 2-10μs/cm or customized | |||
| Ion rejection rate | 99% (new RO membrane) | |||
| Organic rejection rate | >99%, when MW>200 Dalton | |||
| Bacteria rejection rate | >99% | |||
| Ultrapure water quality | ||||
| Resistivity(25°C) | 18.25MΩ.cm | |||
| Microorganism | ＜1cfu/ml | |||
| Particle(>0.1μm) | ＜1pc/ml | |||
| Heavy metal ion | ＜0.1ppb | |||
| Endotoxin(Pyrogens) | N/A | ≤ 0.001EU/ml | ||
| TOC Level*** | ＜ 10 ppb | |||
| Dimension and weight | Bench type: 530*400*590mm, 40Kg; Floor Type: 530*420*1120mm, 75Kg | |||
| Electrical requirements | AC110-240V, 50/60Hz | |||
| Terminal disinfection filter | Optional | |||
| UV lamp | ||||
| UF | ||||
| Standard configuration | Main body (Including 1 set of cartridge)+water tank | |||
| Capacity can be selected | 20L/H, 40L/H, 60L/H, 80L/H, 100L/H, 120L/H | |||
○ Automatic operation.
○ Automatic clean pre-treatment filters and RO membrane to extend their working life.
○ source water four enhanced purification device (PP + AC + G-PHOS/PP + RO).
○ About 99% desalination rate RO membrane.
○ Self-invented pre-treatment system with automatic double backwash function
○ With power-on self-test, water shortage protection alarm, automatic shutdown with full water, ultra-low voltage protection functions.
○ Comprehensive Information query and management function, water quality, cartridges usage and alarm information.
○ Level II password, protect all the parameters setting, and prohibit any unauthorized setting change.
○ System time setting (year/month/day/hour/minute), timing standby (0-60 minute), and timing shutdown (0-24 hour) function.
○ 2 kind of pure water tank (sterile water tank and pressure tank). Also external tanks is optional.
○ Whole plastic shell with high-strength, avoid rusting and keep clean, to meet GLP standard.
○ 2 door and easy-to-replacing cartridge design, convenient to maintain system and replace cartridges.
○ Tube and adapter with NSF authorization and top quality, reduce TOC level and assure ultrapure water´s quality.
○ RO module with good quality, ensure long life, stable operation and high desalinization rate.
○ Top polishing resin, ensure ultrapure water´s quality up to 18.2 MΩ.cm, with the lowest TOC level.
○ Double wavelength (185&254nm) ultraviolet lamp module, restrain bacteria´s increase and reduce TOC.
○ Terminal disinfection filter, assure that terminal pure water is absolutely axenic.
o ICP-MS(Inductively Coupled Plasma Mass Spectrometry), GFAAS(Graphite Furnace Atomic Absorption Spectrophotometry), HPLC, IC(Ion Chromatography), AAS(Atomic Absorption Spectrophotometry), PCR(Polymerse chain reaction);
o Buffer and media preparation, Electrophysiology, Mammalian and bactrial cell culture, Plant tissue culture, Qualitative analysis, Animal watering, Aquariums, Autoclave feed;
o Feed to ultrapure water machine, Glassware washing/rinsing, Northern and southern blotting, Qualitative analyses, Ultra trace analysis, Weatern blotting.
