Technical Parameters:
| Raw water hardness：＜=8mmol/L | Power consumption：10-40W |
| Power supply： 220V+-22V/50Hz | Water inlet temperature： 2-38℃ |
| Water consumption: <2% of water production | Operating temperature：5℃-50℃ |
| Water pressure： 0.2-0.4Mpa | Total pressure loss of equipment：0.03Mpa |
| Regeneration: dynamic downstream (countercurrent) timing regeneration | |
| Residual hardness of water： <=0.03 mmol/L | |
| Consumption of salt: 100-250g / mol (depending on source water source) | |
| Softening Resin Model: British drift Wright food grade cation exchange resin | |
Model List：
| No. | Model | Water Yield(L/H) | Model of tank with quantity (Dia*H*PC) | Resin Qty (kg) | Salt Tank Size (Dia*H mm) | Feed Water Pipe Size | Working Pressure (Mpa) |
| 1 | ZYRH-250 | 250 | 205*890*1 | 25 | 420*280*1150 | DN20 | 0.2-0.4 |
| 2 | ZYRH-500 | 500 | 255*1370*1 | 45 | 330*750 | DN20 | |
| 3 | ZYRH-1000 | 1000 | 330*1370*1 | 75 | 520*1050 | DN25 | |
| 4 | ZYRH-2000 | 2000 | 400*1650*1 | 150 | 520*1050 | DN25 | |
| 5 | ZYRH-3000 | 3000 | 450*1650*1 | 180 | 520*1050 | DN32 | |
| 6 | ZYRH-4000 | 4000 | 530*1650*1 | 210 | 600*1080 | DN32 | |
| 7 | ZYRH-5000 | 5000 | 530*1850*1 | 275 | 650*1180 | DN40 |
Features:
◎ Fully automatic control. Softener through the program control device, automatically complete the softening work, washing, backwashing, salt, regeneration and other functions
◎ Only need to add the softener special regenerator rugularly.
◎ Efficient: The design of soft water heater is reasonable, so that softening resin works effectively and exchanges capacity to give full play.
◎ Labor saving: No specialized pepole is needed to operate, easy to install.
◎ Water saving : The water-marking rate is more than 98% .
◎ Power saving: due to the use of rain absorption principle, regeneration without salt pump
◎ Period adjustable: according to the need to adjust the softening resin regeneration cycle at any time.
◎ Pipeline simplification, compact structure covers an area of small, saving space
◎ Stable and reliable operation; saving regeneration agent; low operating costs; maintenance-free.
◎ Can be directly with municipal tap water or groundwater docking, deep softening, to ensure that soft water quality.
◎ According to the different degree of water hardness, can be pretreated after softening or secondary softening treatment, according to the actual situation can provide professional design 'installation, training.
