Water Treatment
Automatic RO Water Plant

ZYRO series pure water equipment uses modern new type of reverse osmosis membrane filtration techonlogy to remove more than 99% ions, organic, inorganic, bacteria, colloid, heavy metal ion, particles. 1606376103817891.jpg

Water production 500L/H (Customized is available.)
Working pressure0.2-0.4 Mpa
Water temperature5-40 ℃
RO membrane DN0.0001-0.001um
Ion removal rate≥99%;
 Endotoxin, bacterial removal rate≥99%;
Recovery≥75%;
Effluent conductivity ≤ 15us / cm (source water quality TDS <200ppm)


No.Model

Water yield

(L/H)

Voltage/Power

(V/Kw)

Body Size

(L*W*H mm)

Water Tank

(L/Material)

1ZYRO-250250380/2.51400*700*1640250/stainless steel/PE
2ZYRO-500500380/3.51400*700*1640500/stainless steel/PE
3ZYRO-750750380/4.51400*700*1640750/stainless steel/PE
4ZYRO-10001000380/6.01400*700*16401000/stainless steel/PE
5ZYRO-15001500380/7.01500*800*18001500/stainless steel/PE
6ZYRO-20002000380/8.01500*800*18002000/stainless steel/PE
7ZYRO-30003000380/9.51800*800*20003000/stainless steel/PE
8ZYRO-50005000380/11.51800*800*20005000/stainless steel/PE

 Note: 1. The RO membrane can't produce water when the temperature is lower than 0℃.

2. The machine needs to be changed double RO system or other better configuration if the TDS of feed water is more than 1000ppm.


* Operation: Siemens PLC+touch screen;

* Booster pump: provide pressure to multi-media filter and AC filter;

* Multi-media filter: get rid of turbidity, sediment, silt, rust, ago, colloid and part of organics;

* AC filter: adsorb residual chlorine, color, smell, harmful matter, organic matters;

* Softener resin: exchange Mg2+ and Ca2+ to Na+ to prevent scale;

* Cartridge filtration: filtrate microparticles whose accuracy is larger than 5um;

* High pressure pump: provide pressure to RO membrane;

* RO membrane: 0.0001-0.001um; remove more than 99% salt ions, organic matters, bacteria, virus, endotoxin, etc.

Optional configuration: EDI system, UF system, UV lamp, ozone generator, etc.


1. High-precision filter, the aperture of nano-level, the best water quality

2. Manual / electric control system automatically switch;

3. With a self-test, water-free point automatically open the system of water, water full stop, no pressure protection and other safety devices;

4. With open RO membrane automatic washing and water tank full automatic double wash function, can extend the life of RO membrane;

5.  With on-line monitoring of water quality (conductivity display), flow and pressure on-line display;

6. Equipment integration, installation is simple, simple operation, no special duty;

7. Equipment failure with automatic alarm function;

8.High water production, high desalination rate, long service life;

9. Core components (pumps, RO membrane, electronic control systems, etc.) imported / domestic joint venture brand;

10. Equipment rack with stainless steel, low-pressure pipe for the UPVC material, high-pressure pipe using SUS304 stainless steel.


SUS304 Cheap Price Deionized Water Purification System with ISO9001

*. Beverage, purifier water, distilled water, mineral water, pure water, wine industry;

*. Domestic/home drinking water;

*. Hotel, school, farm, factory;

SUS304 Cheap Price Deionized Water Purification System with ISO9001

Why choose us :

1. Professional manufacturer : More than 10 years experience in prodcuing pure water treatment system.

2. Strict time control : Ensure delivery time.

3. Factory strength:  The factory area is more than 2000m3, more than 100 workers.

4. After-sales service : 24 Hours online for service.

5. Customized is available. Sample order is available.
