Water Treatment
SUS304/316L Reverse Osmosis Water Purification System


Water production 250-10000L/H (Customized is available.)
Working pressure0.2-0.4 Mpa
Water temperature5-40
RO membrane DN0.0001-0.001um
Ion removal rate99%;
 Endotoxin, bacterial removal rate99%;
Recovery75%;
Effluent conductivity ≤ 15us / cm (source water quality TDS <200ppm)


No.Model

Water yield

(L/H)

Voltage/Power

(V/Kw)

Body Size

(L*W*H mm)

Water Tank

(L/Material)

1ZYRO-250250380/2.51400*700*1640250/stainless steel/PE
2ZYRO-500500380/3.51400*700*1640500/stainless steel/PE
3ZYRO-750750380/4.51400*700*1640750/stainless steel/PE
4ZYRO-10001000380/6.01400*700*16401000/stainless steel/PE
5ZYRO-15001500380/7.01500*800*18001500/stainless steel/PE
6ZYRO-20002000380/8.01500*800*18002000/stainless steel/PE
7ZYRO-30003000380/9.51800*800*20003000/stainless steel/PE
8ZYRO-50005000380/11.51800*800*20005000/stainless steel/PE

 Note: 1. The RO membrane can't produce water when the temperature is lower than 0℃.

2. The machine needs to be changed double RO system or other better configuration if the TDS of feed water is more than 1000ppm.


1 Ton Electronic Water Treatment Drinking Water Purifier Plant

* Operation: automatic control;

* Booster pump: provide pressure to multi-media filter and AC filter;

* Multi-media filter: get rid of turbidity, sediment, silt, rust, ago, colloid and part of organics;

* AC filter: adsorb residual chlorine, color, smell, harmful matter, organic matters;

* Softener resin: exchange Mg2+ and Ca2+ to Na+ to prevent scale;

* Cartridge filtration: filtrate microparticles whose accuracy is larger than 5um;

* High pressure pump: provide pressure to RO membrane;

* RO membrane: 0.0001-0.001um; remove more than 99% salt ions, organic matters, bacteria, virus, endotoxin, etc.

Optional configuration: EDI system, UF system, UV lamp, ozone generator, etc.
